Widok 360
Schemat
Wymiary
 d1 [mm] | L Nominal[mm] |  mm | d2 [mm] | K [mm] | W [mm] |  Maxm/m |  E [mm] min – max |  (N) |  (N) |
| 3,2 | 8,0 | 3,30 – 3,50 | 9,5 | 1,10 | 1,80 | 10,00 | 0,5 – 5,0 | 630 | 980 |
| d1 [mm] | L Nominal[mm] | mm | d2 [mm] | K [mm] | W [mm] | Max m/m | E [mm] min – max | (N) | (N) |
| 4,0 | 13,0 | 4,10 – 4,30 | 12,0 | 1,40 | 2,20 | 15,30 | 3,0 – 9,0 | 1050 | 1500 |
| 16,0 | 18,80 | 6,0 – 13,0 |
| d1 [mm] | L Nominal[mm] | mm | d2 [mm] | K [mm] | W [mm] | Max m/m | E [mm] min – max | (N) | (N) |
| 4,8 | 10,5 | 4,90 – 5,10 | 16,0 | 1,80 | 2,75 | 14,00 | 1,5 – 6,0 | 1500 | 2400 |
| 17,0 | 20,00 | 6,0 – 12,5 | |||||||
| 25,0 | 28,00 | 12,0 -19,5 |
